The DDT-1060-ZH is a 10.1-inch capacitive touchscreen operated color video intercom unit door station with an LCD display resolution of up to 1280×800. It adopts high-definition digital camera, which has clear video quality. The new noise suppression technology can obtain high-restoration sound quality effects in different environments. This machine adopts SCHIDERON X7 series CPU chip, Android system architecture, CPU frequency up to 1.2GHZ, memory is 1G DDR-II. It has the advantages of fast operation speed, high intercom audio and video quality, low power consumption of the overall chip, and high operation stability to meet the needs of future upgrades. The interface operation instructions are simple and straightforward, making it easier for users to use. Support public password unlocking, user private password unlocking, IC card access control card unlocking, visitor message photos, call management center and other functions. The overall performance and technical indicators are at the leading level in the industry


Main function introduction

Call indoor terminal and management center video, voice call, indoor unit monitoring, management center monitoring support and elevator linkage control high-definition camera, night LED fill lighting, built-in IC access control module, support card unlocking, through the management center authorization card issuance, support door magnetic (on/off) status detection and delay alarm, support normally open/normally closed electronic lock access


System : Android NET protocol : TCP / IP Bus : S-Net

CPU : X7 Power : DC 12V Working current : ≤180mA

Current : ≤150mA Temperature : -10℃~+50 ℃ Operating HUM : 20%~85%

Material : ABS+Aluminum Webcam : 1.3 million pixels Ringing : Bell≥70dB

Frequency : 1.2G Hz RAM : 1G DDR-II ROM : 8GB

Installation : Embedded Thickness : 8mm Size : 339*190*28.2(mm)

Dust proof : IP55

Parameter file - outdoor door intercom

DDT-007B-HD-X1S(Simplified Chinese) 2018 / 06 / 15 3.43M

DDT-007B-HD-X1S(Traditional Chinese) 2018 / 07 / 19 3.37M

Installation instructions - visual intercom

DDT-007HD-Simplified 2019 / 06 / 03 996.72K

DDT-007HD-Traditional 2019 / 06 / 03 651.04K
